Emerson Fisher Multiport Flow Selector User Manual

Instruction Manual
D104239X012
Multiport Flow Selector
January 2019
43
Menu Parameter Value Units Default
Fd Field diagnostics 0-27 Fault code 0
AH Display Alarm History? 0-1 0=No, Skip to 1
st
Passcode 1=Yes, Display
History
A1 1
st
latest alarm Alarm None
A2 2
nd
older alarm Alarm None
A3 3
rd
older alarm Alarm None
A4 4
th
older alarm Alarm None
A5 5
th
older alarm Alarm None
A6 6
th
older alarm Alarm None
A7 7
th
older alarm Alarm None
A8 8
th
older alarm Alarm None
P1 1
st
Passcode 00-99 None 00
P2 2
nd
Passcode 00-99 None 00
C0 Control Mode 0-1
0=Discrete 1=Network
1
C1 ESD Action 0-1 0=Stop/Stayput 1=Go to Home Port 1
C2 Torque Limit 15-99 Torque in % 77
C3 Network Node Address 1-99 99 = selection of default address 254 for
other protocol CAM modules.
99
C4 Network Baudrate 0-3 0=4800 1=9600
2=19200 3=38400
2
C5 Network Parity 0-2
0=None 1=Odd
2=Even
0
C6 Network Stop Bits 1-2 1=1 Stop bit
2= 2 Stop bits
1
C7 Torque Spring Factor 0-81 None 81
C8 Disable Jog Control 0-1 0=No, 1=Yes 1
C9 Disable Display Timeout 0-1 0=No, 1=Yes 1
CA Home Port Number (0 or 8) 0-1 0=0, 1=8 0
HP Home Port (User selected) 0-7 Port No. 1-7 0
HC Accept Home Port Calibration 0 or 43 0=No, 43=Yes 0
d1 Delete port 1 0-1 0=No, 1=Yes 0
d2 Delete port 2 0-1 0=No, 1=Yes 0
d3 Delete port 3 0-1 0=No, 1=Yes 0
d4 Delete port 4 0-1 0=No, 1=Yes 0
d5 Delete port 5 0-1 0=No, 1=Yes 0
d6 Delete port 6 0-1 0=No, 1=Yes 0
d7 Delete port 7 0-1 0=No, 1=Yes 0
E1 Edit 1
st
Passcode 00-99 None 00
E2 Edit 2
nd
Passcode 00-99 None 00
EP Exit Program? 0-1 0=No, Return to last menu 1=Yes, Exit
Note: RDM port configuration is fixed at 9600,N,8,1 address 254 and may not be changed by the user. Only the network port configuration may be changed. The address programmed
for the network port will be accepted by the RDM port in addition to address 254.
