Emerson Micro Motion Quick Start Guide

□
Cable connection is sealed and secure
Power wiring checklist
□
Terminals positive (+) and negative (–)
□
Ground terminal
□
DC
□
Power
□
18 to 30 VDC
5.3 Specifications
Physical
Sensor housing 304L stainless steel
Electronics housing Polyurethane-painted aluminum
Wetted materials 316L stainless steel
LNGS06 weight 4.6 kg
LNGM10 weight 7.9 kg
With EN1092-1 PN40 F316/316L weld neck
flanges
Cable gland entrances Inlets: Two 3/4” NPT female conduit ports for 9-
wire connection to LNG sensors
Outlets: Two 1/2” — 14 NPT or M20 x 1.5 female
conduit ports for outputs and power supply
Electrical
Output connections
Not intrinsically safe type:
One pair of wiring terminals for RS-485 signal
cable connection for dual core processor and
enhanced core processor with MVD Direct Con-
nect I.S. barrier
Power connections One pair of wiring terminals accepts 24V DC
power for dual core processor and enhanced
core processor with MVD Direct Connect I.S.
barrier
Digital communications Modbus / RS-485 accepts data rates 4800,
9600, 19200, and 38400 baud for dual core pro-
cessor and enhanced core processor with MVD
Direct Connect I.S. barrier
Basic configuration
24 Micro Motion Liquified Natural Gas Meter
