Emerson PNC001-A Series Manual

Battery & Energy Pack Manual Chapter 2
GFK-2741J Oct 2019
Batteries 14
Insert the charging jack into the threaded connector on the side of the battery and hand
tighten the screw lock to secure it.
2.6 Legacy Batteries
2.6.1 IC698ACC701A and IC698ACC701B
The IC698ACC701B (and earlier revisions) coin cell battery pack is a simple battery pack that
provides backup for volatile memory on PACSystems CPUs. The chemistry used in these
batteries does not support the low-battery detection feature. Due to the limited capacity of
this battery pack, it is not compatible with all PACSystems CPUs. Refer to the Battery
Compatibility and Memory Retention Time in days at 20°C (68 °F) chart for CPU
compatibility information.
Specifications
Parameter
Specification
Battery capacity
3.0 amp-hours
Lithium (Li) content
0.87 grams (3 cells @ 0.29grams/cell)
Physical dimensions
76.2 x 26.92 x 12.25mm (3” long x 1.059” wide x 0.4822” high)
Weight
26.5 grams
Connection
60cm (2ft) twisted red/black 22 AWG (0.326mm2) cable with
female two-pin connector compatible with the battery connector
on PAC Systems CPUs.
Operating temperature range
0 to +60ºC (32 to 140°F)
Nominal shelf life
5 years at 20ºC (68°F)
CPU Battery Low Indication
The legacy batteries will not reliably provide the CPU with a battery low indication. User logic
should not rely on any of the battery status bits when using these batteries.
2.6.2 IC693ACC302
The IC693ACC302 Auxiliary Battery module provides an extended backup time for volatile
memory on PACSystems CPUs compared to that of the standard memory backup battery
(IC698ACC701).
Specifications
Parameter
Specification
Battery capacity
15.0 amp-hours
Lithium content
5.1 grams (3 cells @ 1.7 grams/cell)
