Emerson PNC001-A Series Manual

Battery & Energy Pack Manual Chapter 3
GFK-2741J Oct 2019
Energy Packs 31
3.5 PACSystems RX3i Rackless Energy Pack
(IC695ACC403)
3.5.1 Specifications
Part Numbers
IC695ACC403
Energy Pack. Includes base, Cap Pack module and Energy Pack to
Controller cable
IC695ACC413
Replacement Cap Pack module
IC695CBL003
Replacement 0.6m (24”) Energy Pack to CPE400 / CPL410 Controller
cable
Functional Specifications
Dimensions
114.05 × 77.47 × 63.75 mm
(4.49” × 3.05” × 2.51”)
Input voltage range
18–30 Vdc
Input power, maximum
36 W
Output voltage range
18–30Vdc
Output power maximum
45 W
Output current maximum
2.25 A
Backup trip voltage
16.7 Vdc ±4%
Capacitor Pack life expectancy
5 years
Environmental Specifications
The Energy Pack shall be installed in a location that is not exposed to corrosive gases or
liquids, rain, or direct sunlight, and that meets the environmental specifications listed
below.
Operating Temperature, surrounding air
-40˚C to 70˚C
Storage Temperature
-40

C to +85

C (-40°F to 185°F)
Humidity
5% to 95%, non-condensing
3.5.2 Installation & Operation
Refer to PACSystems RX3i Energy Pack IC695ACC403 Quick Start Guide, GFK-3000.
