Emerson PNC001-A Series Manual

Battery & Energy Pack Manual Chapter 3
GFK-2741J Oct 2019
Energy Packs 27
3.2.8 LED Indications
LED
LED State
Energy Pack Status
IN
Green, solid
Input power is applied and within the specified range.
Red, solid
Input power is outside the specified range (20–30Vdc).
Off
Input power is not applied.
STAT
Green,
blinking
Charging of Cap Pack is in progress. No fault exists.
Green, solid
Cap Pack is fully charged and no fault exists.
Amber,
blinking
Cap Pack is nearing end-of-life. The Cap Pack must be replaced soon.
Backup is still guaranteed.
Red, blinking
Internal fault: Cycle power to the Energy Pack. If this does not clear the
fault, contact Technical Support and replace the Energy Pack.
Red, solid
Cap Pack has reached end-of-life. Replace the Cap Pack. Backup is not
guaranteed.
Off
No power applied.
OUT
Green, solid
Output power is within the specified range.
Red, solid
Output power is present but is outside the specified range (20–30 Vdc).
Off
Output power is not present.
LED Indications: Special Cases
All LEDs blinking in unison: See Firmware Updates.
3.2.9 Backup Operation
While the Controller is running, if the input voltage to the Energy Pack falls below 20 Vdc,
the Energy Pack will immediately switch to backup power and signal the Controller to
initiate a memory backup.
The Energy Pack supplies power long enough for the Controller to back up memory and then
turns off power to the Controller. When the input voltage to the Energy Pack returns to
normal, the power-up routine begins.
3.2.10 Service and Maintenance
Replacing the Cap Pack Module
The Cap Pack is typically removed and replaced while power is applied to the Energy Pack
(hot swapped.)
WARNING
When replacing the Cap Pack, potentially hazardous energy could be present. Only handle
by the plastic case. Do not allow a short across the printed wiring assembly components or
connectors.
