Connecting to an External Monitor (EB-W7/X7/S7
only)
You can display computer images input from Computer Input Port on
an external monitor connected to the projector and the screen at the
same time. This means that you can check projected images on an
external monitor when giving presentations even if you cannot see the
screen. Connect using the cable supplied with the external monitor.
A
To Monitor port
B
Cable supplied with monitor
C
To Monitor Out Port
q
• You cannot display images from equipment connected to the
component video signal, Video input port, or S-Video input port
on the external monitor.
• Setting gauges, Configuration Menu, or Help screens for
functions such as Keystone are not output to the external monitor.
• If you want to display images on the external monitor while the
projector is in standby mode, set Extended - Standby Mode to
Communication On from the Configuration menu.s p.53
Connecting to External Equipment (EB-W7/X7/S8/S7 only)
85
