Epson EH-TW7400 User Manual

Configuration Menu
59
c
For items adjusted using an adjustment bar, such as the brightness level, you can press the
button while the adjustment screen is displayed to return the adjustment value to its default value.
Configuration Menu Table
If there is no image signal being input, you cannot adjust items related to the Image or Signal in the
Configuration menu. Note that the items displayed for the Image, Signal, and Info vary depending on the
image signal being projected.
Image menu
Function Menu/Settings Explanation
Color Mode
Dynamic, Bright Cinema, Natural, Cinema, Digi-
tal Cinema, 3D Dynamic, 3D Cinema
Select a color mode based on your sur-
roundings and the image you are projec-
ting.
s p.31
Brightness
Adjusts the brightness when the image
appears too dark.
Contrast
Adjusts the contrast between light and
shade in the images. By increasing the
contrast, the images become vivid.
Color Satura-
tion
Adjusts the color saturation for the im-
ages.
Tint
Adjusts the tint for the images.
Sharpness
Adjusts the image sharpness.
Color Temp.
Color Temp. Adjusts the tint for the images. The image
is tinted blue for high values, and tinted
red for low values.
Skin Tone
Adjusts the skin tone. The image becomes
greener when set to a positive value and
redder when set to a negative value.
Customized
Adjusts the offset and gain for each R, G,
and B color.
Frame Interpo-
lation
*1
Off, Weak, Normal, Strong Adjusts the smoothness of movement of
the image.
Image En-
hancement
*2
4K Enhancement On, Off You can project at a doubled resolution.
Image Preset Mode Off, Preset 1 to Preset 5 Select the settings prepared in advance as
the settings for Noise Reduction, MPEG
Noise Reduction, Super-resolution, and
Detail Enhancement.
Noise Reduction
Adjusts the roughness of the image.
MPEG Noise Reduction
Smoothes out rough images in MPEG for-
mat.
Super-resolution Fine Line Adjust, Soft
Focus Detail
Adjusts the amount of enhancement for
complicated images and backgrounds.
Detail Enhancement
Creates a more emphatic texture and ma-
terial feel of the image.

Epson EH-TW7400 Specifications

General

Matrix size	0.74 \
Number of colors	1.07 billion colors
Native aspect ratio	16:9
Projection distance	3 - 6.3 m
Vertical scan range	192 - 240 Hz
Projection technology	3LCD
Contrast ratio (typical)	200000:1
Screen size compatibility	50 - 300 \
Projector native resolution	WUXGA (1920x1200)
Keystone correction, vertical	-30 - 30 °
Throw ratio	1.35 - 2.84:1
Zoom capability	Yes
Focal length range	22.5 - 46.7 mm
Aperture range (F-F)	2 - 3
Vertical lens shift range	-96.3 - 96.3 %
Horizontal lens shift range	-47.1 - 47.1 %
Lamp type	UHE
Lamp power	250 W
Light source type	Lamp
Service life of light source	3500 h
Service life of light source (economic mode)	5000 h
Video processing	10 bit
Video color modes	Cinema, Dynamic, Natural, Bright cinema
Supported 3D formats	Side by side, Top and bottom
3D video colour modes	3D Dynamic, 3D Cinema
Analog signal format system	Not supported
DVI port	No
Audio (L/R) in	-
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Home cinema
Cable lock slot type	Kensington
Noise level	31 dB
Country of origin	China
2D/3D frequency image	240/480 Hz
Noise level (economic mode)	20 dB
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	355 W
Power consumption (economy mode)	271 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Cables included	AC, HDMI
Pallet width	800 mm
Pallet height	2510 mm
Pallet length	1200 mm
Pallet weight	0 g
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	16 pc(s)
Quantity per pallet layer	2 pc(s)
Harmonized System (HS) code	85286200
Software support	via: AMX, Crestron (Network), Control4

Weight and Dimensions

Depth	450 mm
Width	520 mm
Height	193 mm
Weight	11200 g
Package depth	655 mm
Package width	512 mm
Package height	260 mm
Package weight	14425 g
