Epson LX-350 User Manual

The printer has a minimum and a maximum top-of-form position. If you try to adjust it beyond these
limits, the printer beeps and stops moving the paper.
When the paper reaches the default top-of-form position, the printer also beeps and stops moving the
paper briefly. You can use the default position as a reference point when adjusting the top-of-form
position.
After you set the top-of-form position, press the Pause button to exit the Micro Adjust mode.
Top
Advancing the paper to the tear-off edge
If you use the push tractor, you can use the tear-off feature to advance your continuous paper to the printer’s tear-off edge
when you finish printing. You can then easily tear off the printed document. When you resume printing, the printer
automatically feeds the paper back to the top-of-form position so that you can save the paper normally lost between
documents.
As described below, you can use the tear-off feature in two ways: manually, by pressing the printer’s Tear Off (Font) button,
or automatically, by turning on the auto tear-off mode.
Caution:
Never use the tear-off feature (as described below) to feed continuous paper with labels backwards; they may
come off their backing sheet and jam the printer.
Using the Tear Off button
After the printer finishes printing your document, check that the Tear Off (Font) light is not flashing. Then press the Tear Off
(Font) button. The printer advances the paper to the tear-off edge.
Note:
If the Tear Off (Font) light is flashing, the paper is in the tear-off position. If you press the Tear Off (Font)
button again, the printer feeds your paper to the next top-of-form position.
Advancing the paper to the tear-off position automatically
To automatically advance your printed documents to the tear-off position, you need to turn on the auto tear-off mode and
select the appropriate page length for continuous paper in the Default Setting mode. For instructions, see Changing default
settings.
When auto tear-off is on, the printer automatically advances the paper to the tear-off position whenever it receives a full page
of data or a form feed command followed by no more data.
Adjusting the tear-off position
If your paper’s perforation is not aligned with the tear-off edge, you can use the Micro Adjust feature to move the perforation
to the tear-off position.
Follow these steps to adjust the tear-off position:
Caution:
Never use the paper feed knob to adjust the tear-off position; this may damage the printer or cause it to lose
the tear-off position.

Epson LX-350 Specifications

General

print speed (draft high-speed)	347 cps (10 cpi), 357 cps (12 cpi), 390 cps (15 cpi)
print speed (draft high-speed condensed)	383 cps (17 cpi), 298 cps (20 cpi)
print speed (draft)	260 cps (10 cpi), 312 cps (12 cpi), 223 cps (15 cpi)
print speed (draft condensed)	222 cps (17 cpi), 260 cps (20 cpi)
print speed (draft in bold)	130 cps (10 cpi)
print speed (near letter quality)	65 cps (10 cpi), 78 cps (12 cpi), 55 cps (15 cpi), 47 cps (17 cpi), 56 cps (20 cpi)
column width	80 cpl (10 cpi), 96 cpl (12 cpi), 120 cpl (15 cpi), 137 cpl (17 cpi), 160 cpl (20 cpi)
cut sheets width	3.9 ~ 10.1" (100 ~ 257 mm)
cut sheets length	3.9 ~ 14.3" (100 ~ 364 mm)
cut sheets thickness	0.0025 ~ 0.0055" (0.065 ~ 0.14 mm)
multiple forms width	3.9 ~ 10.1" (100 ~ 257 mm)
multiple forms length	3.9 ~ 14.3" (100 ~ 364 mm)
multiple forms thickness	0.0047 ~ 0.015" (Total) (0.12 ~ 0.39 mm)
envelopes (No.6) width	6.5" (165 mm)
envelopes (No.6) length	3.6" (92 mm)
envelopes (No.6) thickness	0.0063 ~ 0.0205" (Total) (0.16 ~ 0.52 mm)
envelopes (No.10) width	9.5" (241 mm)
envelopes (No.10) length	4.1" (105 mm)
envelopes (No.10) thickness	0.0063 ~ 0.0205" (Total) (0.16 ~ 0.52 mm)
continuous forms width	4.0 ~ 10.0" (101.6 ~ 254.0 mm)
continuous forms length (per sheet)	4.0 ~ 22.0" (101.6 ~ 558.8 mm)
continuous forms thickness	0.0025 ~ 0.015" (Total) (0.065 ~ 0.39 mm)
paper roll holder width	8.5" (216 mm)
paper roll holder thickness	0.0028 ~ 0.0035" (0.07 ~ 0.09 mm)
copies	1 original + 4 copies
format space between lines	1/6" (4.23 mm) or programmable in increments of 1/216" (0.118 mm)
voltage	AC 120 V / AC 220 - 240 V
frequency	50 Hz / 60 Hz
power consumption	27 W (ISO/IEC 10561 Letter pattern)
power consumption in sleep mode	Approx. 1.1 W
power consumption in powered off mode	0 W
power consumption in auto off mode	Approx. 0.3W
temperature	41 ~ 95°F
humidity	10 ~ 80% RH
mean time before failure	10, 000 POH (at 25% duty)
print head life	400 million strokes/wire
sound level	Approx. 53 dB(A) (ISO 7779 standard)
interfaces	Bidirectional parallel (IEEE-1284), USB high speed (ver 2.0), Serial
input buffer	128KB

Weight and Dimensions

width	14.25" (13.7" without knob)
depth	10.83"
height	6.06"
weight	9.04 lb
