Epson LX-350 User Manual

Home > Control Panel
Lock-Out Mode
Changing the lock-out mode setting
You can restrict the use of buttons on the control panel by using the lock-out mode.
Changing the lock-out mode setting
You can turn lock-out mode on or off or change locked functions from lock-out setting mode.
The following table shows the basic function of each button in the lock-out setting mode.
Button Basic function
Item button
Selects the next menu parameter.
Item button
Selects the previous menu parameter.
Set button Changes the value in the selected menu.
You can select the printer functions to be locked while the lock-out mode is on according to your needs.
Note:
Before entering the lock-out setting mode, you need to load A4 or letter size single-sheet paper or
continuous paper that is at least 210 mm (8.3 inches) wide. See Printing on Continuous Paper and
Printing on Single Sheets for instructions on loading continuous paper and single sheets.
For your safety, Epson recommends operating the printer with the printer cover closed. The printer will
function with the printer cover open or removed, but for maximum safety keep the cover closed.
Follow these steps to change the lock-out mode setting:
Make sure the printer is turned off.
Caution:
Whenever you turn off the printer, wait at least five seconds before turning it back on; otherwise, you may
damage the printer.
Turn on the printer while holding down both the LF/FF and Pause buttons.
The printer enters the lock-out setting mode and prints a message asking if you wish to print all of the current settings.
If you want to print the current settings, press the Set button. If you want to bypass printing of the current settings,
press the Item button or the Item button.
The printer prints the first menu and the current value of the menu.
Press the Item button or the Item button to select the menu parameters which you wish to change. Press the Set
button to scroll through the values within the selected parameter until you find the desired setting. After setting the
selected parameter to the desired setting, you may continue to make changes to other parameters by pressing the Item
button or the Item button.
Turn off the printer and exit the lock-out setting mode.

Epson LX-350 Specifications

General

print speed (draft high-speed)	347 cps (10 cpi), 357 cps (12 cpi), 390 cps (15 cpi)
print speed (draft high-speed condensed)	383 cps (17 cpi), 298 cps (20 cpi)
print speed (draft)	260 cps (10 cpi), 312 cps (12 cpi), 223 cps (15 cpi)
print speed (draft condensed)	222 cps (17 cpi), 260 cps (20 cpi)
print speed (draft in bold)	130 cps (10 cpi)
print speed (near letter quality)	65 cps (10 cpi), 78 cps (12 cpi), 55 cps (15 cpi), 47 cps (17 cpi), 56 cps (20 cpi)
column width	80 cpl (10 cpi), 96 cpl (12 cpi), 120 cpl (15 cpi), 137 cpl (17 cpi), 160 cpl (20 cpi)
cut sheets width	3.9 ~ 10.1" (100 ~ 257 mm)
cut sheets length	3.9 ~ 14.3" (100 ~ 364 mm)
cut sheets thickness	0.0025 ~ 0.0055" (0.065 ~ 0.14 mm)
multiple forms width	3.9 ~ 10.1" (100 ~ 257 mm)
multiple forms length	3.9 ~ 14.3" (100 ~ 364 mm)
multiple forms thickness	0.0047 ~ 0.015" (Total) (0.12 ~ 0.39 mm)
envelopes (No.6) width	6.5" (165 mm)
envelopes (No.6) length	3.6" (92 mm)
envelopes (No.6) thickness	0.0063 ~ 0.0205" (Total) (0.16 ~ 0.52 mm)
envelopes (No.10) width	9.5" (241 mm)
envelopes (No.10) length	4.1" (105 mm)
envelopes (No.10) thickness	0.0063 ~ 0.0205" (Total) (0.16 ~ 0.52 mm)
continuous forms width	4.0 ~ 10.0" (101.6 ~ 254.0 mm)
continuous forms length (per sheet)	4.0 ~ 22.0" (101.6 ~ 558.8 mm)
continuous forms thickness	0.0025 ~ 0.015" (Total) (0.065 ~ 0.39 mm)
paper roll holder width	8.5" (216 mm)
paper roll holder thickness	0.0028 ~ 0.0035" (0.07 ~ 0.09 mm)
copies	1 original + 4 copies
format space between lines	1/6" (4.23 mm) or programmable in increments of 1/216" (0.118 mm)
voltage	AC 120 V / AC 220 - 240 V
frequency	50 Hz / 60 Hz
power consumption	27 W (ISO/IEC 10561 Letter pattern)
power consumption in sleep mode	Approx. 1.1 W
power consumption in powered off mode	0 W
power consumption in auto off mode	Approx. 0.3W
temperature	41 ~ 95°F
humidity	10 ~ 80% RH
mean time before failure	10, 000 POH (at 25% duty)
print head life	400 million strokes/wire
sound level	Approx. 53 dB(A) (ISO 7779 standard)
interfaces	Bidirectional parallel (IEEE-1284), USB high speed (ver 2.0), Serial
input buffer	128KB

Weight and Dimensions

width	14.25" (13.7" without knob)
depth	10.83"
height	6.06"
weight	9.04 lb
