Disassembly/Reassembly Disassembly/Reassembly Procedures 30
Epson WF-7620/7610/7110 Series Revision B
2.2.2 Functional differences between models and component parts
WF-7620/7610/7110 Series described in this manual have differences in their structure because the same printer
mechanism is used for some of them and the composition of housings or functions differs.
The functions and differences according to the models are as follows.
Therefore, parts and units are colored and classified into 2 types in the flowchart given in this section.
After checking the functions and differences in the components shown above, see the disassembly procedures.
Table 2-2. Function List According to Models
Item
Multifunction Printer Single function Printer
WF-7620 Series WF-7610 Series WF-7110 Series
ADF/Scanner
Compatible O O ---
Non-compatible --- --- O
Panel
Electrostatic Pad type O O ---
LED & Button type --- --- O
Second cassette (Frame Base 2nd) O --- O
FAX O O ---
Wireless LAN O O O
Disassembly Flowchart Start Position p 32 p 33
Table 2-3. Components According to Functions
Item Specification
ADF/Scanner
The following units and parts are not mounted on the models without the ADF/Scanner.
• ADF Unit
• Scanner Unit
Panel Unit
With Panel Unit, the shape, components and disassembly order in the disassembly procedures differ depending
on the specification of the panel.
Second cassette
(Frame Base 2nd)
The following units and parts are not mounted on the models without the second cassette.
• Frame Base 2nd Assy
With Multifunction Printer, the disassembly procedures differ depending on whether or
not having the Second cassette.
• Paper Stopper Assy 1st
• Pickup Assy 1st
• Lower Case
FAX The FAX Unit is not mounted on the model without the FAX.
Common parts/units in Multifunction Printer or Single function Printer Black
Model-specific parts/units Red
To Next Page
