Firex PMKIE100 User Manual

INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND
USE Rev−12
PMKIE−DIMU−GB−12
17 GB
INDIRECT TILTING PANS, ELECTRIC TYPE
ˆPMKIE100˜ ˆPMKIE150˜ ˆPMKIE200˜ ˆPMKIE300˜ ˆPMKIE500˜
3.6.1 POSSIBLE FAILURES AND THEIR ELIMINATION
Only technically qualified service centres can perform the operations described
below!
Before resetting the safety thermostat, it is always necessary to eliminate the problem
causing its activation
Problem and possible cause Access to components and operation
The content of the vat does not heat up:
− the safety thermostat has been
activated;
− the heating elements have a failure;
− failure to contactors
− failure unit level
− selector/switch failure.
− operating thermostat failure.
− failure pressure
− failure switches tipping tank for heating
Safety thermostat
The safety thermostat is placed on the pan’s bottom (rear).
Heating elements
The heating elements are accessible after lifting the tank about
50/60 ° and having dismantled the lower rear panel .
Contactors - unit level
The contactors are accessible after removing the lower front
panel on the frame right. Pull the box and remove the cover.
Switch / Operating-thermostat working-pressure-limit
switch
To enter you must remove the right side panel.
The movement of the tank can not 'be
done
− failure to fuses
− failure motor tipping board
− failure switches motor
− motor fault tipping
− failure switches cover (modd.200-300-
500)
Fuses-Motor tipping board
Are accessible after removing the lower front panel on the frame
left. Pull the box and remove the cover
Switches motor- motor tipping
To enter you must remove the left side panel.
limit switch cover
To enter you must remove the rear cover of the block of the
hinge cover.
THE SAFETY VALVE OPEN
− Contactors (bonding)
− Pressure switch (calibration)
− Safety valve (if it opens at lower
pressures than calibration), replace it.
Contactors
The contactors are accessible after removing the lower front
panel on the frame right. Pull the box and remove the cover
Pressure Switch
To enter you must remove the right side panel.
Safety valve
Safety group the right rear of the tank
