Firex PMKIE100 User Manual

INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND
USE Rev−12
PMKIE−DIMU−GB−12
7 GB
INDIRECT TILTING PANS, ELECTRIC TYPE
ˆPMKIE100˜ ˆPMKIE150˜ ˆPMKIE200˜ ˆPMKIE300˜ ˆPMKIE500˜
1.7 TECHNICAL DATA PMKIE
PMKIE 100 150 200 300 500
TECHNICAL DATA (DIMEMSIONS)
Equipment dim.A mm 1445 1445 1596 1726 1726
Equipment dim.B mm 1190 1190 1310 1380 1380
Equipment dim.H mm 1090 1090 1090 1090 1090
Equipment dim.H2 mm 2000 2000 2165 2320 2320
TECHNICAL DATA (FUNCTIONALITY)
Kettle diameter mm
600
600
750
900
900
Pan dimension H mm
415
580
520
520
780
Overvall volume lt
113
161
220
325
496
Useful volume lt
102
150
200
300
470
Temperature °C 20÷110
Liters H20 jacket lt 32 32 50 65 65
Jacket pressure kPa 85 85 55 55 55
TECHNICAL DATA (INSTALLATION)
Electric power kW
16
18
32
3
6
36
Voltage/Input (standard)** V 380-415 V 3 50/60Hz
IPX IPX 4
Rated current *** A 24,3 27,3 48,6 54,7 54,7
Cable connection *** nr x mm² 4 X 6 4 X 6 4 X 10 4 X 16 4 X 16
Water pressure kPa 50-300
Hot water inlet Ø" 3/4"
Cold water inlet Ø" 3/4"
Sound level dbA < 70
TECHNICAL DATA (STORAGE/MOVEMENT)
Packaging dim.A mm 1590 1590 1740 1840 1840
Packaging dim.B mm 1340 1340 1440 1540 1540
Packaging dim.H mm 1470 1470 1470 1470 1470
Volume m³ 3,131 3,131 3,658 4,165 4,165
Net weight kg 258 370 425 410 450
Gross weight kg 308 420 505 490 530
**Verify on data plate - ***Current and cable for standard tension

Firex PMKIE100 Specifications

General

Brand	Firex
Model	PMKIE100
Category	Kettle
Language	English
