Fisher GX User Manual

Instruction Manual
D103175X012
GX Valve and Actuator
July 2017
42
Parts Kits
PACKING
KITS
Valve Size
Stem Diameter
DN15 to DN50
(NPS 1/2 to 2)
10 mm
DN80 and DN100
(NPS 3 and 4)
14 mm
DN150
(NPS 6)
19 mm
ENVIRO-SEAL PTFE packing (Contains keys 32 and 33) RGXPACKX012 RGXPACKX022 RGXPACKX072
ENVIRO-SEAL Graphite ULF packing (Contains keys
42, 43, and 44)
RGXPACKX052 RGXPACKX042 RGXPACKX082
ACTUATOR
KITS
Actuator Size 225 750 1200
Actuator (Contains keys 10, 15, 19, 109, and 20) RGX225X0022 RGX750X0032 RGX1200X042
BALANCED
SEAL KITS
(1)
Valve Size
DN80
(NPS 3)
DN100
(NPS 4)
DN150
(NPS 6)
Nitrile (Contains keys 37 and 38) RGXSEALX012 RGXSEALX022 RGXSEALX072
Ethylene Propylene (EPDM) (Contains keys 37 and 38) RGXSEALX032 RGXSEALX042 RGXSEALX082
FKM Fluorocarbon (Contains keys 37 and 38) RGXSEALX052 RGXSEALX062 RGXSEALX092
1. A Gasket Kit is required when replacing the seals.
GASKET
KITS
Valve Size
DN15 to DN25
(NPS 1/2 to 1)
DN 40
(NPS 1‐1/2)
DN 50
(NPS 2)
DN 80
(NPS 3)
DN 100
(NPS 4)
DN 150
(NPS 6)
Body / Bonnet Gasket Kit
(Graphite Laminate)
(Contains key 5)
GE00077X012 GE00078X012 GE00079X012 GE00080X012 GE00052X012 RGASKETXA62
Body / Bonnet Gasket and
Extension Bonnet Gasket Kit
(Graphite Laminate)
(Contains keys 5 and 47)
RGASKETXA12 RGASKETXA22 RGASKETXA32 RGASKETXA42 RGASKETXA52 ‐ ‐ ‐
Body / Bonnet Gasket,
Extension Bonnet Gasket,
and Bellows Gasket
(Graphite Laminate)
(Contains keys 5, 47, and 50)
RGASKETXB12 RGASKETXB22 RGASKETXB32 RGASKETXB42 RGASKETXB52 ‐ ‐ ‐
REPAIR NAMEPLATE
Description
DN15 to DN150
(NPS 1/2 to 6)
18‐8 stainless steel nameplate. Will mount to all GX actuator sizes
using casing bolt. See figure 29.
GE11233X012
