Camera parts

7.4 View from the bottom

7.4.1 Figure

7.4.2 Explanation

1. Latch to open the cover for the battery compartment. Push to open.

#T559845; r. AJ/37554/37554; en-US

Default Chapter5
- Table of Contents5
