FORMULER Z8 User Manual

http://iptv-rivesud.com http://tv-diablo.com iptv.rivesud@gmail.com
30
Auto recording / Auto turn on and off
 If you set up a recording, you do not have to leave your Formuler on.
 The box will wake up from standby/sleep mode itself and record what is
scheduled.
 When completed, it will go back to the previous power state.
See the video
https://youtu.be/GDs4Fl31No0?list=PL1SsTffwqZZwCy8DA_2AsQE8Z34GdkLcM
Record current program / channel
To record channels, you need a USB drive (dongle or external hard drive, etc.) to store
recordings.
Please follow the steps below to record a current program.
1. Insert a USB into your Formuler
2. In Live TV, go over a channel you want to record
3. or Bring up the grid EPG by pressing the EPG/Guide button on the remote and
go over a channel
4. Press the RECORD (●) button (small round red button) on the remote
5. When the recording works, you will see recording is progressing on the right
top of the screen
󰌏󰌐 Adjust current recording duration.
1. Press the RECORD (●) button on the remote while recording
2. Recording Details window will show up
3. Now you can set a recording duration

FORMULER Z8 Specifications

General

Storage media type	eMMC
Built-in storage media	Yes
Card reader integrated	No
Total storage capacity	16 GB
Product color	Black
Supported radio bands	-
Audio formats supported	AAC, AAC HE, MP1
Image formats supported	BMP, GIF, JPG, PNG
Video formats supported	AVI, AVS, FLV, H.264, H.265, HEVC/H.265, MKV, MOV, MP4, MPEG1, MPEG2, MPEG4, RM, TS, VC-1, VP9
Maximum video resolution	3840 x 2160 pixels
Audio output channels	- channels
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Processor cores	4
Internal memory	2000 MB
Internal memory type	DDR4
AC input voltage	12 V
Power consumption (standby)	0.5 W
Power consumption (typical)	15 W

Weight and Dimensions

Width	105 mm
Height	22 mm
