11 | Individualization and data transfer Franke Kaffeemaschinen AG
76 User manual SB1200 FM CM
11.3 Requirements for your own media
Media Advertising images
(advertising media)
Product images Screen saver Video files (advertising media)
Size
800x600px 430x274px 800x600px Max. 800x600px (4:3) or
800x450px (16:9)
Data formats
24-bit PNG 24-bit PNG and 8-
bit alpha channel
(if necessary)
24-bit PNG AVI (Codec H263, DivX/Xvid,
MPEG-4 Part 2)
Bit rate: Max. 200kbps, image fre-
quency: Max. 25fps
Storage loca-
tion on the
USB stick
Folder: \QML-
Files\rc\cus-
tom\images
Folder: \QML-
Files\rc\cus-
tom\drinks
Folder: \QML-
Files\rc\cus-
tom\screensavers
Folder: \QML-Files\rc\cus-
tom\images
11.4 Multimedia functions
– Use image files or video files as advertising media
– Use image files or video files as a screen saver
11.5 Required directory structure on the USB stick
You must maintain a specific directory structure so that the coffee machine can recognize your media without any
difficulty.
Creating a directory structure on the machine
1. Connect a USB stick to the machine.
2. Go to the Individualization and data transfer > 1
Manage my media menu.
3. Click on the menu item 1.8 Create directory struc-
ture.
ð The directory structure will be created on the
USB stick.
Directory structure
[Drive]\ QML-Files\ rc\ custom\ drinks
images
screensavers
11.6 Loading or deleting your own media
The upload process is the same for all media.
Free space: 400 MB
The images on the USB stick must be present in the required folder structure, have the correct data format, and be
of the correct size. See Requirements for your own media (without multimedia).
