Synergic Central control panel
General The functions on the control panel are all arranged in a logical way. The individual param-
eters required for welding can be
- selected easily using buttons
- altered using buttons or the adjusting dial
- displayed on the digital display during welding
The power source uses the Synergic control panel and certain general items of data such
as sheet thickness, filler metal, wire diameter and shielding gas to calculate the best weld-
ing parameters. As a result, stored knowledge is available at all times. All the parameters
can be adjusted manually. The Synergic control panel also allows parameters to be set
manually.
Safety
Synergic control
panel
NOTE! Due to software updates, you may find that your device has certain func-
tions that are not described in these operating instructions or vice versa. Individ-
ual illustrations may also differ slightly from the actual controls on your device, but
these controls function in exactly the same way.
WARNING! Operating the equipment incorrectly can cause serious injury and
damage. Do not use the functions described until you have thoroughly read and
understood the following documents:
- these operating instructions
- all the operating instructions for the system components, especially the safe-
ty rules
(1)
(2)
(3)
(4)
(5)
(6)(7)
(14)
(15)
(11)
(12)
(10) (8)(9)
(13)
