Control Panel
59
Product Overview
2
23 One touch buttons
(Only available for
machines with the Fax
service)
Allows you to specify a recipient with the simple press of a button. You
can use the buttons for fax and Internet fax jobs.
Turn over the panels to display buttons 1 - 72.
There are two ways in which address numbers and stored programs are
assigned to the one touch buttons. Select either of the following:
z
[Type 1]
The buttons 1 to 70 are used for address numbers and they
correspond to the registered address numbers 0001 to 0070, while the
buttons 71 and 72 are used for stored programs and they correspond
to the registered stored programs 1 and 2.
z
[Type 2]
The buttons 1 to 60 are used for address numbers and they
correspond to the registered address numbers 0001 to 0060, while the
buttons 61 to 72 are used for stored programs and they correspond to
the registered stored programs 1 to 12.
Note • By default, [Type 1] is selected.
• This feature is not available for some models. An optional
component is required. For more information, contact our
Customer Support Center.
For information on how to change the settings registered to the one touch
buttons, refer to "5 Tools" > "Common Service Settings" > "Screen/Button
Settings" in the Administrator Guide.
24 Embedded IC Card Reader
(optional)
Used to authenticate a user using a smart card.
When you touch the smart card to the IC Card Reader, the machine
reads the user information registered on the smart card and
authenticates the user.
Note • An optional component is required to use this feature. For more
information, contact our Customer Support Center.
• When the machine is in the Energy Saver mode, touching the
smart card to the IC Card Reader deactivates the Energy Saver
mode. However, this operation does not deactivate the Sleep
mode. For more information, refer to "Exiting the Energy Saver
Mode" (P.55).
25 Paper clip tray Used for placing paper clips and staples.
No. Component Function
