71
3.2 Scanning Documents Longer than A3
3
SCANNING VARIOUS TYPES OF DOC-
3.2 Scanning Documents Longer than
A3
When scanning documents longer than A3, set the feeding option to “Long Page”.
This scanner can scan documents up to 863mm long.
Below is the procedure with TWAIN driver.
1. Set the document on the hopper.
Refer to section “2.6 Loading Documents on the Hopper” on page 17.
2. Adjust stacker in accordance with document size.
Refer to section “2.7 Setting up the Stacker” on page 22.
3. Start TWAIN driver with the application used.
Refer to section “2.13 How to use the Scanner Driver” on page 41.
HINT
When scanning long pages (longer than A3), the document may be longer
than the stacker extension even if it’s pulled to the outermost position. In
case like this, place a thick paper about the size of A4 on the stopper and
make a slope as depicted below.
(The scanner can scan documents up to 863mm long.)
Stopper
Stacker Extension
Thick Paper
To Next Page
