13-2. Wireless remote controller (AR-RED1U/AR-REG1U)
¢
Overview
• AR-RED1U
Signal
Transmitter
MIN. HEAT
button
TEMP.
button
POWERFUL
button
START/STOP
button
MODE button
SENSOR button
ECONOMY button
OUTDOOR UNIT
LOW NOISE button
SWING button
TIMER SETTING button
SEND button
SELECT button
NEXT button
BACK button
SET button
WEEKLY button
ON/OFF button
SLEEP button
FAN button
RESET button
CLOCK ADJUST button
NOTE: Functions may differ by type of the indoor unit. For details, refer to the operation manual.
Display panel
To facilitate explanation, the accompanying illustration has been drawn to show all possible indicators; in actual operation,
however, the display will only show those indicators appropriate to the current operation.
MODE indicator
ENERGY SAVING
PROGRAM indicator
LOW NOISE MODE
indicator

Turns ON when the
SENSOR button is operated.
CLOCK & TIMER
indicator
SEND indicator
TEMPERATURE indicator Transmit indicator
FAN Speed indicator
SWING indicator
To facilitate explanation, the accompanying illustration has been drawn to show all possible indicators;
in actual operation, however, the display will only show those indicators appropriate to the current oper-
ation.
- 114 -
13-2. Wireless remote controller (AR-RED1U/AR-REG1U) 13. Remote controller
MULTI TYPE 2, 3, 4 ROOMS TYPE MULTI TYPE 2, 3, 4 ROOMS TYPE
