Fujitsu LIFEBOOK E782 User Manual

Removing and installing com ponents
during servicing
Removing and installing compo
nents
during servicing
Only qualified technicians should repair your notebo ok. Unauthorised
opening or incorrect repair may greatly endanger the user (electric shock,
fire risk) and will invalidate y our warran ty.
Components
Serv icing
After consulting the Hotline/Service Desk, you may remove and install the
components described in this chapter yourself.
If you remove and install components without consulting the Hotline/Service
Desk, then the warranty of your note book will be voided.
Notes on installing and removing boards
and components
• Switch the notebook off and pu ll t he power plug out of the mains socket.
• Always remove the battery.
• Take care when you use the locking mechanisms on the ba ttery and any other component.
• Never use sharp objects such a s screwdrivers, scissors or knives as leverage to remove covers.
NotesBoardESD
Boards with electrostatic sensitive d e vice s (ESD) are marked w ith the label
shown.
When handling boards fitted with ESDs, you must always observe the following
points:
• You must always discharge static build up (e.g. by touching a grounded
object) before working.
• The e quip ment and tools y ou use must be free of static charges.
• Remove the power plug fro m the mains supply before inserting or removing
boards containing ESDs.
• Always hold boards w ith ESDs by their edges.
• Never touch pins or conductors on boards fitted with E SDs.
68 Fujitsu Technology Solutions

Fujitsu LIFEBOOK E782 Specifications

General

Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-3210M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-3200 Mobile series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	2.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.1 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	25
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM77 Express
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
HDD size	2.5 \
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MS PRO Duo, MS PRO Duo HS, SD, SDHC, SDXC
Number of HDDs installed	1
Display diagonal	15.6 \
Display brightness	220 cd/m²
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Audio system	HD
Front camera resolution	1920 x 1080 pixels
Front camera resolution (numeric)	2 MP
4G standard	WiMAX
Data network	-
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile network generation	4G
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	0
Pointing device	Touchpad
Recovery operating system	Windows 8 Pro
Operating system installed	Windows 7 Professional
Form factor	Clamshell
Product type	Laptop
Product color	Black, Grey
Processor code	SR0N0
Processor ARK ID	65708
Processor package size	31.0 x 24.0 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery capacity	6700 mAh
Battery life (max)	12 h
Number of battery cells	6
AC adapter power	80 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	4.22 A
AC adapter output voltage	12 V
Sustainability certificates	RoHS, EPEAT Gold, ENERGY STAR
Certification	CE, CB, Nordic Swan, WEEE, HCT, HCL entry, WHQL

Weight and Dimensions

Depth	245 mm
Width	372 mm
Height	33 mm
Weight	2400 g
