Fujitsu LIFEBOOK E782 User Manual

Settings in BIO S Setup Utility
Settings in BIOS Setup Utility
BIOSSetupUtilitySystemsettings,BIOSSetupUtilityConfiguration,BIOS SetupUtilitySetupSystemc onfigurationHardwareconfiguration
The BIOS Setu p Utility allows you to set the system functions and the hardware
configuration for the notebook.
When it is delivered, the notebook is set to fact ory default settings. You can
change these settings in BIOS Setu p Utility. Any cha nges yo u make take effect as
soon as you save and exit the BIOS Setup Utility.
The BIOS Setup Utility program contains the following menus:
About
Displays information relating to the BIOS, processo r and notebook
System
Advanced system settings
Advanced
Configuration of va
rious hardware components, such as mouse, keyboard,
processor
Security
Password settings and security functions
Boot
Configuration of the start-up se quence
Exit
Exits the BIOS Setu p Utility
Starting the BIOS Setup Utility
► Reboot the device (switch off/on or reboot the operating system).
BIOSSetupUtili
ty

The following or a similar display app ears on the screen at start-up:
<F2> BIOS Setup <F12> Boot Menu
► Press the fu nction key
F2
.
► If a password has been assigned, enter the password and press the Enter key.
If you have forgotten the password, contact your system administrator
or contact our customer service centre.
The BI
OS Setup Utility starts.
Operating BIOS Setup Utility
BIOSSetupUtility
Press the
F1
key to display help on the operation of the BIOS Setup Utility. The description
of the individual settings is shown in the right-hand window of the BIOS Setup Utility.
With the
F9
key you can load the default settings of the BIOS Setup Utility.
► Use the cursor keys
←
or
→
to select the menu you wish to access to make changes.

The m enu is displaye d on the screen.
► Select the option you want to change with the cursor keys
↑
or
↓
.
► Press the Enter key.
► Press the
ESC
key to exit the selected menu.
► For future reference, make a note of the changes you have made (for example, in this manual).
Fujitsu Technology Solutions 75

Fujitsu LIFEBOOK E782 Specifications

General

Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-3210M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-3200 Mobile series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	2.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.1 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	25
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM77 Express
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
HDD size	2.5 \
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MS PRO Duo, MS PRO Duo HS, SD, SDHC, SDXC
Number of HDDs installed	1
Display diagonal	15.6 \
Display brightness	220 cd/m²
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Audio system	HD
Front camera resolution	1920 x 1080 pixels
Front camera resolution (numeric)	2 MP
4G standard	WiMAX
Data network	-
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile network generation	4G
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	0
Pointing device	Touchpad
Recovery operating system	Windows 8 Pro
Operating system installed	Windows 7 Professional
Form factor	Clamshell
Product type	Laptop
Product color	Black, Grey
Processor code	SR0N0
Processor ARK ID	65708
Processor package size	31.0 x 24.0 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery capacity	6700 mAh
Battery life (max)	12 h
Number of battery cells	6
AC adapter power	80 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	4.22 A
AC adapter output voltage	12 V
Sustainability certificates	RoHS, EPEAT Gold, ENERGY STAR
Certification	CE, CB, Nordic Swan, WEEE, HCT, HCL entry, WHQL

Weight and Dimensions

Depth	245 mm
Width	372 mm
Height	33 mm
Weight	2400 g
