Fujitsu LIFEBOOK P770 User Manual

68 - Memory Upgrade Module
Installing a Memory Module
1 Align the connector edge of the memory upgrade module, chip side up, with the connector slot in the
compartment.
(Figure 24)
2 Insert the memory upgrade module at a 45
o
angle and press it firmly onto the connector.
3 Press the memory upgrade module down into the compartment until it locks underneath the retaining clip. You
will hear a click when it is properly in place.
4 Replace the memory compartment cover. (Figure 25)
Figure 24. Inserting a Memory Module Figure 25. Reinstalling the Memory Cover
T
HE MEMORY UPGRADE MODULE IS NOT SOMETHING YOU ROUTINELY REMOVE FROM YOUR LIFEBOOK
NOTEBOOK. ONCE IT IS INSTALLED, YOU SHOULD LEAVE IT IN PLACE UNLESS YOU WANT TO INCREASE
SYSTEM MEMORY CAPACITY.
