- Locating the Controls and Connectors
Keyboard
A full-size keyboard with dedicated Windows keys. See “Keyboard” on page 23.
Air Vents
The air vents allow air to circulate through the system to cool down the components.
SD Card Slot
The SD card slot allows you to install a Secure Digital (SD) card for data storage. This architecture allows you to transfer
data from a variety of different digital devices. See “Installing SD Cards” on page 67.
Wireless Device On/Off Switch
The wireless device on/off switch is used to turn on and off the optional WLAN and Bluetooth devices. Switching the
device off when not in use will help to extend battery life. See “Activating the WLAN Device” on page 145.
Microphone Jack
The microphone jack allows you to connect an external mono microphone. See “Microphone Jack” on page 77.
Headphone Jack
The headphone jack allows you to connect headphones. See “Headphone Jack” on page 76.
Touchpad Pointing Device
The Touchpad pointing device is a mouse-like cursor control with two buttons (left and right). To the right of the touch
pad is a scroll wheel. See “Touchpad Pointing Device” on page 26. Between the two buttons is a fingerprint sensor
device for logging on to your system without a password. See “Appendix B: Fingerprint Sensor Device” on page 153.
TO PROTECT YOUR NOTEBOOK FROM DAMAGE AND TO OPTIMIZE PERFORMANCE, BE SURE TO KEEP ALL AIR VENTS UNOBSTRUCTED, CLEAN, AND
CLEAR OF DEBRIS. THIS MAY REQUIRE PERIODIC CLEANING, DEPENDING UPON THE ENVIRONMENT IN WHICH THE SYSTEM IS USED.
D
O NOT OPERATE THE NOTEBOOK IN AREAS WHERE THE AIR VENTS CAN BE OBSTRUCTED, SUCH AS IN TIGHT ENCLOSURES OR ON SOFT SURFACES LIKE
A BED OR CUSHION.
