Getting started
Connecting the device
Please observe the safety information in "Important notes", Page 7.
CE conformance and optimum picture quality are guaranteed only if
you use the data cables supplied.
► Switch off the monitor and the comp uter.
► Disconnect the power plug
from the computer.
Connecting cables to the monitor
The mon itor ports are pr
otected by a cover.
The supplied data cable
s have two 15-pin D-SUB connecto rs or two 24-pin DVI connectors
or two 20-pin D P-conne
ctors for connection to the monitor and to the computer.
Informationontheco
mputer connections and interfaces is contained in the
operating m anual fo
r the compute r.
1
2
10
345 678910
1=Securi
ty slot for "Kensington Lock"
2=Cover
3=Power
connector
4=0Wswitch
5=DPco
nnector
6=DVI-Ds
ocket (DVI)
7 = D-SUB socket (VGA)
8 = AUDIO
-IN socket
9 = USB IN (Downstream)
10 = USB O
UT (Upstrea m)
