Getting started
Connecting the device
Please observe the s afety information in "Important notes", Page 7.
CE conformance and optimum picture quality are guaranteed only if
you use the data ca bles supplied.
► Switch off the monitor and the computer.
► Disconnect the power plug
from the computer.
Connecting cables to the monitor
The mon itor ports are pr
otected by a cover.
The supplied data cable
s have two 15-pin D-SUB connectors or two 24-pin DVI connectors
or two 20-pin DP-conne
ctors for connection to the monitor and to the computer.
Informationontheco
mputer connections and interfaces is contained in the
operating m anual fo
r the compute r.
11
1
2
43 5 6 7 9 10
11
8
1=Securi
ty slot for "Kensington Lock"
2=Cover
3=Power
connector
4=0Wswitch
5=DPco
nnector
6 = DVI-D socket (DVI)
7=D-SUBs
ocket (VGA)
8 = HD MI sockets
9 = AUDIO
-IN socket
10 = USB IN (Dow nstream)
11 = USB O
UT (Upstrea m)
► Remove the cover.
Fujitsu Technology Solutions 15
