Getting s tarted
► Select th e appropriate data cable for your computer.
► Connect one of the connectors of t he data cable to the DVI-D socket or the DP s ocket of
the monitor and secure the DVI-D connection by tightening the safety screws.
If you use a DP or HDMI data cable, you must set the 0 W switch to the basic position.
If yo u use a VGA or DVI D ual Link data cable, when the PC is switched off you can
move the 0 W switch to the ECO position to enable the 0 W power saving mode.
The mon itor automatically detects the input (VGA, DVI, D P) when
only one signal source is connected.
An H DMI input must always be selected manually. The change from HDMI to V GA ,
DVI, D P or the 2nd HDMI input can also only be done man ually.
► Insert one connector of the audio line in the AUDIO IN (9) socket on the
monitor and make sure it is properly engaged.
► Plug the power cable s
upplied into the power connector of the monitor.
► Plug th e supplied USB cable into the U SB IN socket (10) and the other end
of the cable into a USB socket of th e computer.
Connect the USB keyboard and USB mouse directly to the PC, as the USB connector
socket o f the monitor is switched off in energy-saving mode.
► Secure the cover over the connections.
A lock (Kensingto n Lock) can be mounted in the security slot to protect the monitor
against theft. A Kensington lock is not supplied with the monitor.
Connecting cables to the computer
Information on the computer con nections and interfaces is contained in the
operating m anual for your computer.
► Connect the data cable to the (active) monitor port on the computer and secure
the plug-in connection by tightening the safety screws.
► Insert the othe r plug of the audio cable in the audio output of the computer.
► Plug the power connector of the monitor into a properly grounded mains outlet.
► Plug th e power connector of the computer into a properly grounded mains outlet.
If your computer has two monitor ports ("onboard" screen controller and separate
graphics card), the monitor port for the separate graphics card is active as standard.
16 Fujitsu Technology Solutions
