2.2 Server specification
System Board
Processor
Memory Modules Configuration
System board type D3349
Chipset Intel C602J Chipset
Processor quantity and
type
2-4x E7-48xx/88xx v3 series
Processor notes A minimum of 2 processors (1+2) must be
configured, no mix of different processor types
Memory slots 96 (distributed on 8 memory boards with 12 slots
each)
Memory slot type DIMM (DDR4) 1333/1600/1866 RDIMM, LR-DIMM
Memory capacity
(from - to)
Min. 32 GB - Max. 6144 GB
Memory protection Advanced ECC, SDDC, Memory mirroring support,
Hot-spare memory support
Memory notes Memory modules are installed on memory boards
(12 DIMM slots per memory board). Two memory
boards are preinstalled in base unit, further memory
boards as option.
Memory module notes Memory modules will be delivered in sets of
2 DIMMs per order code.
Intel C104 Scalable Memory Buffer supports max.
1866 MHz memory clock speed.
