Fujitsu ScanSnap iX100 User Manual

Connecting a Computer in Direct Connect Mode
By using the ScanSnap Wireless Setup Tool Wizard, you can configure and check the connection
between the ScanSnap and a computer.
For details, refer to "Setting a Wireless LAN Using the ScanSnap Wireless Setup Tool" (page 57).
The following explains how to connect the ScanSnap and a computer when the computer to be
connected has already been registered by using the ScanSnap Wireless Setup Tool Wizard.
1. Click in the notification area located at the far right of the taskbar, and
connect the ScanSnap network displayed in the wireless network list.
The ScanSnap network name (SSID) and the security key are printed on the label attached to
the bottom of the scanner.
HINT
The network name (SSID) and the security key can be checked or changed with the ScanSnap
Wireless Setup Tool.
2. Disconnect the USB cable connecting the ScanSnap to the computer.
ATTENTION
If the ScanSnap Manager icon is , exit ScanSnap Connect Application on the mobile device.
a The ScanSnap is automatically connected to a computer via wireless LAN and the
ScanSnap Manager icon changes to .
If the icon does not change, go to step 3.
HINT
l If the [Connect automatically to previous ScanSnap by Wi-Fi] checkbox is selected and the
previously connected ScanSnap is available for the connection, the computer is connected to
the ScanSnap automatically.
l The computer can be connected to only one ScanSnap.
l Only one computer can be connected to the ScanSnap via wireless LAN.
l When you automatically connect a computer and the ScanSnap that had been connected via
wireless LAN before, if the password for the ScanSnap to be connected is changed, a
notification informs you of the status.
3. Right-click the ScanSnap Manager icon
in the notification area located at
the far right of the taskbar and select [Connect by Wi-Fi] from the "Right-
Click Menu" (page 45).
a The [ScanSnap Manager - Connect by Wi-Fi] window appears.
4. From the list of the ScanSnap units to be connected, select the ScanSnap
that you want to connect, and click the [Connect] button.
Connecting the ScanSnap via Wireless LAN
62

Fujitsu ScanSnap iX100 Specifications

General

Color scanning	Yes
Duplex scanning	No
Maximum scan size	216 x 360 mm
Optical scanning resolution	600 x 600 DPI
Flatbed scan speed (b/w, A4)	5 sec/page
Black/white scanning color modes	Grayscale, Monochrome
Scanner type	CDF + Sheet-fed scanner
Product color	Black
Sensor type	CIS
Built-in processor	GI
Daily duty cycle (max)	- pages
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Scanning media types supported	Business Card, Photo paper, Plain paper, Post Card(JPN)
Maximum ISO A-series paper size	A4
USB version	2.0
Standard interfaces	USB 1.1, USB 2.0, Wireless LAN
Current	0.5 A
Input voltage	5 V
Battery capacity	720 mAh
Power supply type	AC/Battery
Power consumption (standby)	0.5 W
Power consumption (typical)	4.7 W
Power consumption (PowerSave)	2.2 W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	RoHS, ENERGY STAR
Cables included	USB
Bundled software	ScanSnap Manager 6.3\\r ScanSnap Organizer\\r CardMinder 5.2\\r ABBYY FineReader for ScanSnap 5.0\\r Scan to Microsoft SharePoint
Minimum scan size	25.4 x 25.4mm
Scan media weight	52 - 209 g/m²
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	47.5 mm
Width	273 mm
Height	36 mm
Weight	470 g
