Technical data
Technical data
Condensation is not permissible either in the rated range of operation
or in the limit range of operation.
P17-3P
P19-3/P19-3P
Dimensions and weight
Visible diagonals 43 cm 48 cm
Dot pitch 0.264 mm 0.294 cm
Width 337.9 mm 376.3 mmImage size
Height 270.3 m m 301 mm
Maximum resolution 1280 x 1024 1280 x 1024
Width 375 mm 412 mm
Height 469 mm 497 mm
Dimensions incl.
monitor base
Depth 249 mm 249 mm
Width 438 mm 484 mm
Height 418 mm 452 mm
Dimensions of box
Depth 176 mm 176 mm
Weight (without packaging)
approx. 6.8 kg approx. 7.5 kg
Storable display modes
25 25
Pixel error classes
accordingtoISO
13406-2
Class
II II
Electrical data
Analog
Positive, 0.7 V
ss
,75Ω
Video
Digital DVI-D
Synchronisation Separate Sync. T TL, positive or neg ative
Horizontal frequen cy 30 kHz .... 82 kHz (multi-scanning)
Refresh rate
56 Hz .... 76 Hz
Maximum pixel rate 135 MHz
Power supply switches automatically, 100 V – 240 V, 50 Hz
–60Hz
Normal operation Max. brightness 34 W
acc. to EPA 29 W
P19-3 max. brightness
38 W acc. to EPA 26 W
P19-3P max.
brightness 38 W acc.
to EPA 31 W
Overall power draw
Power saving mode < 1 W in power saving mode
(Standby mode, Suspend mode and OFF mode)
Sound output 2.0 W left; 2.0 W right
A26361-K1240-Z120-7619, edition 1 31
