Furuno CH-500 User Manual

ix
SYSTEM CONFIGURATION
Display Unit
MU-121C
Control Unit
CH-502
CH-602
External monitor*
(MU-150HD or
market equivalent)
*: XGA only.
Transceiver Unit
CH-503
Rectifier Unit
RU-1746B-2
Loudspeaker
CA-151S-ASSY
Navigational Equipment/
Fish Finder/
Heading Sensor/
Current Indicator/
Water Temp.Sensor
Sonar/
Fish Finder/
Current Sensor
100/110/220/
230 VAC,
1ø, 50/60 Hz
12-24 VDC
Rectifier Unit
RU-1746B-2
Hull Unit
CH-504/505
: Standard supply
: Option or local supply
100/110/220
/230 VAC,
1ø, 50/60 Hz
12/24 V DC
Remote
Controller
CH-256
Remote
Controller
CH-256
KP signal
NMEA0183×2
Control Unit
CH-502
CH-602
NMEA2000 Equipment
NMEA2000
