2. WIRING
2-13
2.1.4 Alert interface types and maximum number of alert interfaces
The EC-3000 has the following alert interface types and quantities:
• IEC 61162-1/2 (4 ports)
• IEC 61162-1 (4 ports)
• IEC 61162-450 (1 port)
2.2 Monitor Unit
For the wiring of the monitor unit, see the operator’s manual supplied with the monitor
unit.
Mounting consideration
<Standard type>
• Connect the ECDIS main monitor to the DVI1 and COM1 ports.
• For the sub ECDIS monitor, connect it to the DVI2 and COM2 port.
<Conning type>
• ECDIS main monitor: DVI1 and COM1 ports, conning monitor: DVI3 port and COM2
ports
• When an ECDIS sub monitor is added to the above connection, connect it to the
DVI2 port (the brilliance adjustment is not available).
<Monitor Color Calibration>
For the following monitor, it is required to calibrate monitor color ([Monitor Color Cali-
bration]) on the [Common Installation Settings] menu. For how to calibrate monitor col-
or, see the instruction manual (E42-01204).
<Notice for HD24T22 FUD-MA1-FxGx>
For the monitor unit HD24T22 FUD-MA1-FxGx, do not use the monitor cascade func-
tion (connect to the VGA Output port in the connection) as shown in the following fig-
ure. This installation is not available for the ECDIS.
<Notice for HD55T22 FUD-MA1-FxGx>
For the monitor unit HD55T22 FUD-MA1-FxGx, attach the ferrite core (type: Wurth
742 711 31) to the optional cable DSUB9P-X2-A-L5M/10M for brilliance control.
• HD19T21 MMD • HD24T21 MMD • HD24T22 FUD
• HD26T21 MMD • HD26T22 MMD • HD26T22 FUD
• HD27T22 FUD • HD32T22 FUD • HD55T22 FUD
EC-3000 HD24T22 VGA Monitor
DVI-I port
VGA port
DVI In VGA Output
To Next Page
