APPENDIX
AP-3
Menu Tree - Inland AIS
ADRS TYPE
(BROAD CAST, ADRS CAST)
MMSI
MSG TYPE
(NORMAL, SAFETY)
CHANNEL
(ALTERNATE, BOTH A & B, A, B)
RETRY TIMES (0-3)
CREATE MSG
TX LOG
RX LOG
SET MSG TYPE
SET MSG
SEND MSG
TEXT
ETA/RTA
NO. OF PERSONS
EMMA WARNING
WATER LEVEL
[MENU] key
MSG
SENSOR STATUS (Display sensor status.)
INTERNAL GPS (Displays data about internal GPS receiver.)
(Continued on next pa
g
e)
USER
SETTINGS
INITIAL
SETTINGS
SET INT ANT POSN
A (0-511 (m))
B (0-511 (m))
C (0-63 (m))
D (0-63 (m))
SET MMSI (MMSI, IMO NO., NAME, CALL SIGN, ENI)
SET EXT ANT POSN
MODE (STANDARD, MONITOR, SERVICE, BEACON, DISABLE)
SPEED (4800BPS, 9600BPS, 19.2KBPS, 38.4KBPS, 57.6KBPS)
SET COM1 MODE (LONG RANGE, EXT DISPLAY, DISABLE)
SPEED (IEC61162-1, IEC61162-2)
SET COM2 MODE (EXT DISPLAY, MONITOR, HI LEVEL IF, DISABLE)
SPEED (IEC61162-1, IEC61162-2)
SET COM3 (Same as SET COM2.)
SET COM4 MODE (SENSOR, EXT DISPLAY, DISABLE)
SPEED (IEC61162-1, IEC61162-2)
SET COM5 MODE (SENSOR(Fixed)
SPEED (IEC61162-1, IEC61162-2)
SET COM6 MODE (SENSOR(Fixed)
SPEED (IIEC61162-1, IEC61162-2, AD-10)
CREATE MSG
ETA LOG
RTA LOG
SET MSG TYPE
SET DESTINATION
SET ETA
SEND MSG
COUNTRY CODE, LOCATION CODE,
FAIRWAY NO., TERMINAL CODE,
FAIRWAY HECT
ETA (DATE, TIME), AIR DRAUGHT,
NO. OF TUGBOATS
CREATE MSG
TX LOG
ADRS TYPE
(BROAD CAST, ADRS CAST)
MMSI
TYPE
(SOLAS(IFM16), INLAND(RFM55))
CHANNEL
(ALTERNATE, BOTH A & B, A, B)
RETRY TIMES (0-3)
SET MSG TYPE
VIEW MSG
SEND MSG
CPA (0.0-6.00 (NM))
TCPA (0-60 (min))
ALARM MODE (ON, OFF)
ALARM BUZZER (ON, OFF)
KEY BEEP (ON, OFF)
ALARM BUZZER (ON, OFF)
AUTO SORT (ON,OFF)
DISP SART TEST (ON, OFF
LONG RANGE
RECEIVED MSG
CPA/TCPA ALARM
LANGUAGE (ENGLISH, FRENCH, DUTCH, GERMAN)
TIME DIFF (-14:00 to +14:00)
RANGE CPA UNITS (NM, km)
SOG UNITS (kn, km/h)
LENGTH UNITS (m, dm)
POPUP (ALL, ABM, OFF)
BUZZER (ON, OFF)
A (0-511 (m))
B (0-511 (m))
C (0-63 (m))
D (0-63 (m))
Note: The INITIAL SETTINGS sub-menu shown
here is the one accessed with a password,
which permits changing of settings. If
accessed without a password, in which
case "SET" in a menu title is replaced with
"VIEW" and settings cannot be changed.
SET SHIP TYPE (Type no.)
SET I/O
PORT
SET
COM
PORT
SET PC
PORT
LR MODE (AUTO, MANUAL)
MSG27 TX (ON, OFF)

Furuno FA-150 Specifications

General

Modulation	GMSK
Operating Temperature	-15°C to +55°C
Frequency	156.025 MHz to 162.025 MHz
Display	LCD
Frequency Range	156.025 MHz to 162.025 MHz
Current Consumption	1.5 A (max)
