8.3 T/A, TEST, RESET DSP
8-10
1.4 PROG. VER.
Displays the program version of connecting unit.
PROGRAM VERSION
FM-8800 : 0550215-02
HS-8800 : 0550216-01
HS-8800 : 0550216-01
HS-8800 : 0550216-01
HS-8800 : 0550216-01
IF-8820 : 0550217-01
Press [SHIFT] key once and [1] key 5 times. The detailed program version is
shown.
PROGRAM VERSION
FM-8800 : 0550215-02-0x
HS-8800 : 0550216-01-0x
HS-8800 : 0550216-01-0x
HS-8800 : 0550216-01-0x
HS-8800 : 0550216-01-0x
IF-8820 : 0550217-01-0x
2. PANEL
2.1 LCD TEST
Press this item and press [ENT] key to carry out LCD contrast test. You can adjust the
contrast level from 0-15 by turning a Channel Knob.
The detailed Ver. is the last 2 digits.
- Remote Handset version number is indicated from a
low ID number in order. (See page.4-4 for details.)
- Version number of the unconnected unit is no
indicated.
0123456789 : ;< >?
ABCDEFGHIJKLMNO
PQRSTUVWXYZ \
’abcdefghijklmno
pqrstuvwxy012345
0123456789 :;<=>? ABCDE
FGHIJKLMNOPQRSTUVWXYZ [
] ’abcdefghijklmnopq
rstuvwxy0123456789:;<=
>? ABCDEFGHIJKLMNOPQRS
TUVWXYZ [ ] ’abcdefghi
jklmnopqrstuvwxy012345
0123456789 : ;< >?
ABCDEFGHIJKLMNO
PQRSTUVWXYZ \
’abcdefghijklmno
pqrstuvwxy012345
0123456789 :;<=>? ABCDE
FGHIJKLMNOPQRSTUVWXYZ [
] ’abcdefghijklmnopq
rstuvwxy0123456789:;<=
>? ABCDEFGHIJKLMNOPQRS
TUVWXYZ [ ] ’abcdefghi
jklmnopqrstuvwxy012345
0123456789 : ;< >?
ABCDEFGHIJKLMNO
PQRSTUVWXYZ \
’abcdefghijklmno
pqrstuvwxy012345
0123456789 :;<=>? ABCDE
FGHIJKLMNOPQRSTUVWXYZ [
] ’abcdefghijklmnopq
rstuvwxy0123456789:;<=
>? ABCDEFGHIJKLMNOPQRS
TUVWXYZ [ ] ’abcdefghi
jklmnopqrstuvwxy012345
LCD TEST [ENT]
[ENT]
[ENT]
LCD Cont. = 06
LCD Cont. = 00
LCD Cont. = 15
[CHANNEL] knob or [ ] ADJ.
[CHANNEL] knob or [ ] ADJ.
16 step
PROGRAM VERSION
FM-8800 : 0550220-01-0x
HS-8800 : 0550221-01-0x
HS-8800 : 0550221-01-0x
HS-8800 : 0550221-01-0x
HS-8800 : 0550221-01-0x
2006-01-25 20:11
Compiled time of the FM-8800
