Furuno FMD-3200 Installation Manual

EQUIPMENT LISTS
v
Trackball Control
Unit
RCU-026 -
Bracket Assembly OP26-5 000-016-270 For MU-190, w/knobs
OP26-15 001-116-730 For MU-231
OP26-30 001-439-060 For MU-270W
IPX2 Kit OP24-23 001-171-780 For EC-3000
Flush Mount OP24-24 001-171-790 For RCU-024
OP24-27 001-171-820 For RCU-026
Connection Stand
(19)
OP24-25 001-171-800 For RCU-024, FMD-3200
Connection Stand
(23)
OP24-26 001-171-810 For RCU-024, FMD-3300
Case Gasket OP24-28 001-169-970 For MC-3000S
OP24-29 001-169-960 For MC-3010A/3020D/3030D
Hood Assembly OP26-6 001-080-930 For MU-190
OP26-16 001-116-740-01 For MU-231
Flush Mount Kit OP26-12 001-116-280 For MU-190
OP26-13 001-116-290 For two MU-190s
OP26-18 000-017-273 For two MU-231s
OP26-14 001-116-300 For three MU-190s
OP26-19 000-017-274 For three MU-231s
OP26-17 001-116-750 For MU-231
Flush Mount
Assembly (Rear)
OP26-31 001-439-070 For MU-270W
Mounting Bracket OP26-21 001-139-310 For MU-190
Monitor Replace-
ment Kit
OP26-22 001-139-320 For MU-190, flush mounting
OP26-23 001-139-360 For MU-190, desktop mounting
OP26-26 001-139-390 For MU-190, hood
OP26-27 001-139-570 For MU-231, desktop mounting
Control Unit
Replacement Kit
OP24-31 001-181-700 For RCU-024
Hood Assembly OP26-24 001-139-370 For MU-190
OP26-25 001-139-380-01 For MU-231
Hood Assembly
(Front)
OP26-32 001-439-090 For MU-270W
Hood Assembly
(Rear)
OP26-33 001-439-110 For MU-270W
Connection Stand
(27)
OP26-34 001-462-860 For MU-270W
Terminal Opener OP24-33 001-188-850
EC-3000 Attach-
ment Kit
OP24-36 001-258-180 For EC-3000
Program Install
Software
OP24-37 001-258-590
Replacement Kit OP24-50 000-027-446
Unit Mounting Base OP24-51 001-461-600 For ECN-319/323/327
FAN-LED Kit OP24-052 001-462-730 For ECN-319/323/327
Name Type Code No. Remarks

Furuno FMD-3200 Specifications

General

Display Type	LCD
Power Supply	24 VDC
Operating Temperature	-15°C to +55°C
ECDIS	Yes
Waterproof Standard	IP22
Interfaces	USB
Chart Format	S-57, S-63
Weight	Approx. 9.5 kg
