1. OPERATIONAL OVERVIEW
1-17
1.14 Cursor
The cursor functions to find the range and bearing (default function) to a target or the latitude and
longitude position of a target. Roll the trackball to position the cursor and read the cursor data at
the screen bottom.
Cursor data
Cursor data
Cursor data can be shown as latitude and longitude or range and bearing from own ship to the
cursor. Position and heading bearing signal are required.
1. Press the MENU key to open the menu.
2. Choose the Mark menu and press the ENTER key
3. Choose Cursor Position and press the ENTER key.
4. Choose Brg/Rng or Lat/Long as appropriate and press the ENTER key. (Note that cursor lati-
tude and longitude position cannot be displayed when nav data is displayed.)
5. Press the MENU key to close the menu.
Cursor data
(latitutde and longitude
or range and bearing)
+ 110.1°R 2.525 NM
