FUTABA 10CAP User Manual

35
Modulation select (
MODUL
): sets the type of modulation transmitted.
The modulation of your receiver will determine whether you utilize FM (
PPM

PCM
or
2.4G-10CH

7CH
setting in
MODUL
during transmission. Note that you have to turn your transmitter off and back on before a modulation change becomes
effective. If you choose
PCM
or
2.4G-10CH

7CH
, be sure you understand and set the FailSafe (
F/S
) settings as you intended
(see p. 50). When utilize PPM or PCM setting, use the TP-FM module. When you utilize
2.4G-10CH

7CH
setting, use the
TM-10 2.4GHz module.
PCM
= Pulse Code Modulation
PPM
= Pulse Position Modulation (also called FM)
2.4G-10CH

7CH
= FASST-2.4GHz system (
10CH
PRGH
7CH
mode)
Adjustability:
•
PCM
setting for all Futaba PCM1024 receivers, regardless of number of
FKDQQHOVLH5'3'3'3'3'36'36'36
•
PPM
setting for all Futaba compatible (negative shift) FM receivers, regardless
of number of channels (ie. R127DF, R123F, R138DF, R148DF).
• Not compatible with PCM512 receivers such as the R128DP and R105iP.
• Not compatible with other brands of PCM receiver, or positive shift FM
UHFHLYHUVLH-5$LUWURQLFV
• You do not need a different module in the radio to transmit in
PCM
. For more
information on
PCM
, please see our website.
•
2.4G-10CH
setting for all Futaba FASST-2.4G Multi-ch mode receivers,
UHJDUGOHVVRIQXPEHURIFKDQQHOVLH5)65)6
•
2.4G-7CH
setting for all Futaba FASST-2.4G 7ch mode receivers, regardless of
QXPEHURIFKDQQHOVLH5))65)65)6
NOTE: When you change models in
MODEL SELECT
, if the new model is set to the other modulation type,
\RXPXVWF\FOHWKHWUDQVPLWWHUSRZHUWRFKDQJHPRGXODWLRQV7KHPRGXODWLRQZLOOÀDVKRQWKHKRPHVFUHHQ
to remind you until you do so. See p. 30,
MODEL SELECT
, for details.
GOAL of EXAMPLE: STEPS: INPUTS:
Change model 1 from FM (
PPM
) to
PCM
.
Confirm you are currently using the
proper model memory (Ex: 1)
On home screen, check model name and
number on top left and the modulation
on top right. If it is not the correct
model, use
MODEL SELECT
, p. 30.
Open
BASIC
menu, then open
PARAMETER
submenu.
for 1 second.
(If
ADVANCE
, again.)
to 2nd page of menu.
C
to
PARAMETER
.
Go to
MODUL
and change setting.
C
to
MODUL
. to
PCM
.
cycle power ÀDVKHVRQVFUHHQ
Close menu and cycle power.
POWER OFF. POWER ON.
Where next? Now that the model is in the proper modulation, the T10C should communicate
ZLWKWKHUHFHLYHU,ILWGRHVQRWFRQILUPWKHPRGXODWLRQIUHTXHQF\RIWKH
receiver. [Futaba receivers ending in F use
PPM
(ex: R148DF), ending in P use
PCM
(ex: R149DP)].
Change
MODEL TYPE
WRJOLGHUKHOLFRSWHUVHHS
Set
F/S
settings for when
PCM
or
2.4G
receiver sees interference: see p. 50.
Utilize servo
REVERSE
: see p. 38.
Adjust servo travel with
END POINT
: see p. 39.
6HWXSGXDOWULSOHUDWHVDQGH[SRQHQWLDO
D/R
,
EXP
): see p. 42.
