FUTABA 10CAP User Manual

7
A QUICK INTRODUCTION TO THE 10C SYSTEM
TRANSMITTER:
• Large graphic liquid-crystal display panel with 2 buttons, a cursor lever and an easy set up turn-and-press Dial for quick,
easy setup.
• All transmitters include all 3 aircraft types with specialized programming for each, including:
• Airplane (
ACRO
)
•
V-TAIL
• Twin Aileron Servos (
FLAPERON
and
AIL-DIFF
) • Gyro Mixing
•
ELEVON
• Twin Elevator Servos (
AILEVATOR
)
•
AIRBRAKE
• Snap Roll (4 separate directions available)
• Helicopter (8 swashplate types, including CCPM, see page 93)(
HELI
)
• 3 Idle Ups • Throttle and Pitch Curves per Condition
• Revo. Mixing • Gyro Mixing including Separate Settings per Condition
• Delay • Governor Mixing
 6DLOSODQH*OLGHUZLQJW\SHV
GLID 1AIL+1FLP

2AIL+1FLP

2AIL+2FLP
)
•
V-TAIL
• Twin Ailerons (
FLAPERON
and
AIL-DIFF
 )OLJKW&RQGLWLRQV1RUPDO6WDUW
•
ELEVON
• Crow (
BUTTERFLY
6SHHG'LVWDQFH/DQGLQJ
•
OFFSET
(5 conditions)
•
BASIC
menu for quick, easy set up of less complex models.
•
ADVANCE
menu for more complex, unique setups.
• Four electronic TRIM LEVERS for rapid yet precise trim adjustment - no remembering to “store trims” between models
and no more “bumped trims” during transport.
•
IDLE- DOWN
(
ACRO
),
THR-CUT
(
ACRO

HELI
) (engine shut off), and
MOTOR CUT
(
GLID
VHWXSVWRDOORZSUHFLVHHQJLQHPRWRU
control for taxi and landings.
FRPSOHWHPRGHOPHPRULHVZLWKPRUHSHURSWLRQDOCAMPac...
• New stick design with improved feel, adjustable length and tension.
• Triple rates available by setting dual rates to 3-position switches.
• Eight SWITCHES, 3 DIALS and 2 SLIDERS; completely assignable in most applications.
• Trainer system includes the “functional” (
FUNC
) setting, which allows the student to use the 10C’s mixing, helicopter, and
other programming functions even with a 4-channel buddy box. (Optional trainer cord required.)
• With a TP-FM module: transmits in both FM (
PPM
) and
PCM
 E\ VHOHFWLQJPRGXODWLRQF\FOLQJ WUDQVPLWWHU 5HTXLUHV
receiver of proper modulation.
With a TM-10 2.4GHz module: transmits in both
2.4G-7CH
and
2.4G-10CH
E\VHOHFWLQJPRGXODWLRQF\FOLQJWUDQVPLWWHU
Requires receiver of proper modulation.
• Permanent memory storage via EEPROM with no backup battery to service or have fail.
• 10CA transmitter features airplane friendly switch layout, with the trainer switch at the left hand (Mode 2), and a notched
throttle to minimize throttle changes with rudder input. Defaults to
ACRO
model type.
• 10CH transmitter features helicopter-friendly switch layout, with idle-up and throttle hold switches at the left hand, and a
smooth, ratchet-less (unsprung) throttle for perfect hovering. Defaults to
HELI
(
H-1
swashplate type) model type.
• Change transmitter mode from mode 2 to modes 1, 3, or 4. (See P. 17)
Note that in the text of this manual, beginning at this point, any time we are using a feature’s specialized name or
abbreviation as seen on the screen of the 10C, that name, feature, or abbreviation will be exactly as seen on the radio’s
screen, including capitalization and shown in a
DIFFERENT TYPE STYLE
IRUFODULW\$Q\WLPHZHPHQWLRQDVSHFL¿FFRQWURO
on the radio itself, such as moving SWITCH A, KNOB VR(B), or the THROTTLE STICK, those words will be displayed
as they are here.
