Fishnder 90/140 Owner’s Manual 19
Appendix
Appendix
Specications
Fishnder 90
Size: 4.7" W x 4.9" H x 2.43" D (11.9 x 12.4 x 6.1 cm)
Weight: 15.5 oz (.439 kg)
Display: 2.0" W x 3.3" H (5.0 x 8.4 cm), 3.9" (9.9 cm) diagonal,
64 x 128 pixels, black-and-white FSTN display
Usage: 3.5 watts maximum, Nominal: 12 VDC @ 0.15 Amps
Fishnder 140
Size: 6.1" W x 4.9" H x 2.6" D (15.5 x 12.5 x 6.6 cm)
Weight: 18.7 oz. (.530 kg)
Display: 3.2" W x 3.1" H (8.1 x 7.9 cm), 4.7" (9.9 cm) diagonal,
128 x 240 pixels, 4-level gray scale FSTN display
Usage: 8 watts maximum, Nominal: 12 VDC @ 0.5 Amps
Fishnder 90 and Fishnder 140
Case: Fully Gasketed, high-impact plastic alloy Waterproof: IEC 529,
level IPX-7 (submerged to 1 meter for 30 minutes)
Temperature Range: +5°F to 158°F (-15°C to 70°C)
Internal memory backup to retain user settings
Input: 10 to 18 VDC with high voltage protection
Sonar Power Output: 100 watts (RMS), 800 watts (peak-to-peak)
Frequency: 80 kHz (wide) and 200 kHz (narrow)
Depth: 600 foot max depth. (Depth capacity is dependent on water
salinity, bottom type, and other water conditions.)
Specications are subject to change without notice.
Optional Accessories
Purchase the following optional accessories on the Garmin Web site:
Swivel mount for the Fishnder 90—allows your Fishnder 90 to tilt
and swivel on its mounting bracket.
Portable case with battery pack and suction mount transducer—
makes your Fishnder portable, so that it can go on any boat, with no
installation (requires eight D-cell batteries, not included).
Flush mounting kit—mounts your shnder ush on the bulkhead or
cabin wall. Press the side clips to release the Fishnder so you can take it
with you.
Protective cover—protects your product when you are not using it.
Caring for the Fishnder
The Fishnder case is constructed of high quality materials
and does not require user maintenance except cleaning.
190-00582-10_0A.indd 19 12/2/2011 3:08:59 PM
