ALTITUDE ALERTING
The Altitude Alerting function provides the pilot with a visual alert when approaching
the Selected Altitude. Whenever the Selected Altitude is changed, the Altitude Alerter
is reset. The following will occur when approaching the Selected Altitude:
•Passing within 1000 feet of the Selected Altitude, the Selected Altitude (shown
above the Altimeter) flashes for 5 seconds.
•When the aircraft passes within 200 ft of the Selected Altitude, the Selected
Altitude flashes for 5 seconds to indicate that the aircraft is approaching the
selected altitude.
•After reaching the Selected Altitude, if the pilot flies outside the deviation band
(±200 Feet of the Selected Altitude), the Selected Altitude changes to yellow text
on a black background, flashes for 5 seconds.
Altitude Alerting Visual Annunciation
Deviation of ±200 ft
