190-01182-02
GTR 225/GNC 255 TSO Installation Manua
l
Rev. F
Page 5-4
37
PAR DME 100 kHz-A/SERIAL DME HOLD
Out
38
GLIDESLOPE SUPERFLAG
Out
39
PAR DME 100 kHz-B
Out
40
PAR DME 100 kHz-C
Out
41
DME COMMON
In
42
PAR DME 100 kHz-D
Out
43
PAR DME 50 kHz
Out
44
SERIAL DME - DME REQUEST
I/O
45
PAR DME 1 MHZ-A
Out
46
PAR DEM 1 MHZ-B
Out
47
PAR DME 1 MHZ-C
Out
48
RESERVED
--
49
AIRCRAFT GND
In
50
RESERVED
--
51
AIRCRAFT POWER
In
52
AIRCRAFT POWER
In
53
GLIDESLOPE - FLAG
Out
54
PAR DME 100 kHz-E
Out
55
GLIDESLOPE +DOWN
Out
56
PAR DME 1MHZ-E
Out
57
RESERVED
--
58
GLIDESLOPE COMPOSITE OUT
Out
59
RESERVED
--
60
AIRCRAFT GND
In
61
AIRCRAFT GND
In
62
AIRCRAFT GND
In
Pin
Pin Name
I/O
37
39
