190-01182-02 GTR 225/GNC 255 TSO Installation Manual
Rev. F Page 5-15
5.2.10.2.2 King Serial DME Tuning
When SERIAL DME – DATA or SERIAL DME – CLOCK is asserted high and driving a 360 load, the
driver output voltage is not less than 8 V, and when asserted low is not greater than 10 mV.
SERIAL DME – RNAV/CH REQ, SER DME – RNAV MODE, and DME COMMON are considered
active if either the voltage to ground is less than 1.9 V or the resistance to ground is less than 375 . These
inputs are considered inactive if the voltage to ground is 11-33 VDC.
DME COMMON must be pulled low to indicate to the GTR/GNC that it is the device channeling the
DME.
Pins 18, 19, 20, and 41 are configured for King Serial DME tuning.
Pin Name Connector Pin I/O
SERIAL DME - DATA P2002 19 I/O
SERIAL DME - CLOCK P2002 18 I/O
SERIAL DME - RNAV/CH REQ P2002 20 In
SERIAL DME - RNAV MODE P2002 21 In
DME COMMON P2002 41 In
SERIAL DME - DME REQUEST P2002 44 I/O
