65
PHYSICAL
Case: Fully-gasketed, high-impact plastic alloy, waterproof to IPX7
standards
Size: 3.2”H x 6.8”L x 2.2”D (8.1 x 17.3 x 6.5 cm)
Weight: 1.2 pounds (478 g) with batteries
Display: 4.0” diagonal, 240 x 160 pixel, 4-level grayscale, backlit
Antenna: Detachable with standard BNC-type connector
Temp. Range: 5° to 158°F (-15° to 70°C)
1
PERFORMANCE
Receiver: Differential-ready PhaseTrac12
™
Acquisition Time: Approx. 15 seconds (warm start)
Approx. 45 seconds (cold start or user-initialized)
Approx. 5 minutes (AutoLocate
®
)
Update Rate: Once per second, continuous
Position Accuracy: 1-5 meters (3-15 ft) with DGPS corrections
2
15 meters (49 ft) RMS
3
Velocity Accuracy: 0.1 mph RMS steady state
Dynamics: Performs to specifications to 6 g’s
Interfaces: NMEA 0183, RTCM (for DGPS corrections) and RS-232 for
PC interface
Memory Back Up: Internal Lithium Battery, lasts up to 10 years
Appendix B
Specifications
