Connectors
Description
Part
Signal
connector
for
analog
input
and
output
signals.
Analog
in/out
Connector
used
to
connect
the
I/O-bo
x
to
the
ÄKT
A
avant
instrument
.
UniNet-9
Status
indicator
for
service
purposes.
Status
Switches
used
to
configure
I/O-box
E9
as
I/O-box
E9
or
I/O-box
E9,
2nd.
Node
ID
Signal
connector
for
digital
input
and
output
signals.
Digital
in/out
ÄKT
A
avant
User
Manual
29035184
AE
145
4
Optional
instrument
modules
4.12
I/O-box
4.12.1
Overview
of
the
I/O-box
144
146
