Reference tubing
The table below shows the label, diameter, and standard length of the reference capillary.
The capillary is used during the System performance tests. The capillary is not mounted
at delivery.
Volume (μl)Length
(mm)
TubingDescriptionLabel
20400PEEK, o.d. 1/16", i.d. 0.25 mmReference capillaryRef 1
Outlet tubing
The table below shows the labels, diameters, and standard lengths of the outlet tubing.
The tubing is not mounted on delivery.
Volume
(ml)
Length
(mm)
TubingDescriptionLabel
1.21500V9-O: ETFE, o.d. 1/16", i.d. 1.0 mmOutlets from Outlet valve
V9-O or V9H-O
Out1 -
Out32
3.0V9H-O: FEP o.d.1/8", i.d. 1.6 mm
Waste tubing
The table below shows the labels, diameters, and standard lengths of the waste tubing.
The waste tubing is mounted on delivery.
Volume
(ml)
Length
(mm)
TubingDescriptionLabel
1.21500ETFE, o.d. 1/16", i.d. 1.0 mmSystem pump wasteW1
1.21500ETFE, o.d. 1/16", i.d. 1.0 mmSample pump wasteW2
1.21500ETFE, o.d. 1/16", i.d. 1.0 mmpH valve wasteW3
1.21500ETFE, o.d. 1/16", i.d. 1.0 mmSystem wasteW
801500Silicone, o.d. 12 mm, i.d. 8 mmTop tray wasteN/A
701350Silicone, o.d. 12 mm, i.d. 8 mmFraction collector F9-C
waste
N/A
ÄKTA avant User Manual 29035184 AE 439
9 Reference information
9.3 Tubing and connectors
