Location
and
illustration
of
Conductivity
monitor
The
following
illustration
shows
the
location
of
the
Conductivity
monitor
and
also
an
enlargement
of
the
monitor
.
In
both
ÄKT
A
avant
25
and
ÄK
T
A
avant
150
the
monitor
is
labelled
C9
.
Description
Par
t
Description
Part
Conductivity
flow
cell
2
Inlet
1
Conductivity
monitor
cable
4
Conductivity
monitor
3
Outlet
5
ÄKT
A
avant
User
Manual
29035184
AE
99
3
Standar
d
instrument
modules
3.12
Conductivity
monitor
98
100
