CHAPTER 3: IEC 61850 COMMUNICATION MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS)
UR FAMILY – COMMUNICATIONS GUIDE 3-193
3
3.5.6 General (Gen) logical device
The Ctrl logical device contains logical nodes that model UR FlexLogic, Virtual Outputs, non-volatile latches, FlexElements,
and recording (for example, oscillography) functions.
The Ctrl logical device is available when the Advanced IEC 61850 option is purchased with the UR device.
3.5.6.1 Logical node zero (LLN0)
LLN0 is instantiated in all UR family devices implementing the Gen logical device.
Table 3-203: LLN0 data objects
phsθHar(n).units Unit CF R
phsθHar(n).units
.SIUnit
ENUMERATED 1, the code for dimensionless
(percentage)
R
phsθHar(n).units
.multiplier
ENUMERATED -2 R
phsθHar(n).db INT32U CF HThdMHAI#.HPhV.phsθHar(n).db R/W/C
phsθHar(n).zeroDb INT32U CF 0 R
numHar INT16U CF 25 R
numCyc INT16U CF 1 R
evalTm INT16U CF (1/ NOMINAL FREQUENCY) *
1000
R
frequency FLOAT32 CF NOMINAL FREQUENCY R
rmsCyc INT16U CF 1 R
LNName: LLN0 LDevice inst: Gen UR element: Nameplate information for the logical nodes
data obj. data attribute Type FC UR Name Description R/W/C
Beh ENS This logical device’s behavior R
stVal ENUMERATED ST R
stVal ENUMERATED ST LLN0.Beh.stVal of the Master
logical device
R
Health ENS Only instantiated in the Master logical
device
R
stVal ENUMERATED ST LPHD1.PhyHealth.stVal R
On SPS Only instantiated in the Master logical
device
R
stVal BOOLEAN ST R
Off SPS Only instantiated in the Master logical
device
R
stVal BOOLEAN ST R
Zero MV Only instantiated in the Master logical
device
R
mag AnalogueValue MX R
mag.f FLOAT32 0.0 R
Mod ENC Only instantiated in the Master logical
device
R/Ctrl
ctlVal ENUMERATED R
stVal ENUMERATED ST R
ctlModel CtlModels CF LLN0.Mod.ctlModel 2, the code for SBO control with normal
security according to IEC 61850-7-2.
R/C
sboTimeout INT32U CF 30000 R
sboClass SboClasses CF 0 (operate-once) R
operTimeout INT32U CF 0 R
GrRef ORG Reference to root logical device R
LNName: HThdMHAI# LDevice inst: Meter UR element: Harmonics and THD metering
data obj. data attribute Type FC UR Name Description R/W/C
