3-234 UR FAMILY – COMMUNICATIONS GUIDE
SCL LOGGING CHAPTER 3: IEC 61850 COMMUNICATION
3
Table 3-238: Part 8 Tissues
3.9 SCL logging
3.9.1 Overview of process
The process of creating a CID file to import into a UR is described in the Configuring the UR using SCL section on page 3-18.
As described, the file can be created using EnerVista software or other, third party IEC 61850 configuration software. The
file transfer to the UR can be done by EnerVista or another client using one of the specified protocols. Upon receipt of the
complete CID file, the UR attempts to parse the file, extract the configuration data and settings that it requires, verify the
data, and then apply the data. During the data application process, the UR is taken out of service automatically if required.
When complete, the UR goes back to its previous in-service or out-of-service state.
During this entire process, an internal log file in the UR is updated to provide information and possibly error logs that can
be used to check the outcome of the process. Transfer this log file from the UR and examine it. This happens automatically
if EnerVista is used to import the CID file to the UR.
743 CCGR.PmpCtl and CCGR.FanCtl na
744 LN STMP, EEHealth and EEName Y
773 Loc, LocKey and LocSta YPSH and YLTC na
774 ITCI.LocKey na
800 Misspelling in CSYN na
802 CCGR and Harmonized control authority na
808 Presence condition of ZMOT.DExt and new Dos na
831 Setting of ConfRevNum in LGOS Y
838 Testing in Beh=Blocked Y
844 MFLK.PhPiMax, MFLK.PhPiLoFil, MFLK.PhPiRoot DEL->WYE na
849 Presence conditions re-assessing in case of derived statistical
calculation
na
877 QVUB -settings should be optional na
909 Remove ANCR.ColOpR and ColOpL na
920 Resettable Counter is NOT resettable Y
932 Rename AVCO.SptVol to AVCO.VolSpt na
939 Change CDC for ANCR.FixCol na
991 LGOS: GoCBRef (as well as LSVS.SvCBRef) should be mandatory Y
1007 PTRC as fault indicator - Update of description required Y
1044 TapChg in AVCO na
1077 Rename DOnames within LTIM na
Part 8-1
Tissue
Description Implemented by server?
784 Tracking of control (CTS) na
817 Fixed-length GOOSE float encoding na
834 File dir name length 64 Y
951 Encoding of Owner attribute na
1040 More associate error codes Y
1178 Select Response+ is non-null value Y
1324 The response- for DeleteNamedVariableList is not defined na
Part 7 Tissue Description Implemented by server?
