CHAPTER 3: IEC 61850 COMMUNICATION SCL IMPLEMENTATION CONFORMANCE STATEMENT (SICS)
UR FAMILY – COMMUNICATIONS GUIDE 3-225
3
<EnumVal ord="1">Loss of Load</EnumVal>
<EnumVal ord="2">Arc Suspected</EnumVal>
<EnumVal ord="3">Arcing</EnumVal>
<EnumVal ord="4">Overcurrent</EnumVal>
<EnumVal ord="5">Down Conductor</EnumVal>
<EnumVal ord="6">External</EnumVal>
</EnumType>
<EnumType id="GE_Digital_Energy_UR_MotStatusKind">
<EnumVal ord="0">Offline</EnumVal>
<EnumVal ord="1">Starting</EnumVal>
<EnumVal ord="2">Running</EnumVal>
<EnumVal ord="3">Overload</EnumVal>
</EnumType>
<EnumType id="GE_Digital_Energy_UR_RGooseRxModeKind">
<EnumVal ord="0">Unicast</EnumVal>
<EnumVal ord="1">SSM</EnumVal>
<EnumVal ord="2">ASM</EnumVal>
</EnumType>
<EnumType id="GE_Digital_Energy_UR_RGooseSecEnaKind">
<EnumVal ord="0">None</EnumVal>
<EnumVal ord="1">Signature</EnumVal>
<EnumVal ord="2">SignatureAndEncryption</EnumVal>
</EnumType>
<EnumType id="GE_Digital_Energy_UR_TimeSourceKind">
<EnumVal ord="0">None</EnumVal>
<EnumVal ord="1">Port 1 PTP Clock</EnumVal>
<EnumVal ord="2">Port 2 PTP Clock</EnumVal>
<EnumVal ord="3">Port 3 PTP Clock</EnumVal>
<EnumVal ord="4">IRIG-B</EnumVal>
<EnumVal ord="5">SNTP</EnumVal>
</EnumType>
The table outlines the logical nodes and data objects that use the extended enumerations.
Table 3-224: GE extended enumerations usage
3.6 SCL implementation conformance statement (SICS)
The table outlines conformance to the Substation Configuration Language (SCL).
Enum ID Used in logical
node
Using data
object
CDC Semantic
GE_Digital_Energy_UR_HiZStKind HiZPHIZ HiZSt ENS Status of High Impedance fault detection
function
GE_Digital_Energy_UR_TriggerKind HiZPHIZ Trigger11 ENS HIZ Capture1 Trigger Type
Trigger12 ENS HIZ Capture2 Trigger Type
Trigger13 ENS HIZ Capture3 Trigger Type
Trigger14 ENS HIZ Capture4 Trigger Type
Trigger21 ENS HIZ RMS Capture1 Trigger Type
Trigger22 ENS HIZ RMS Capture2 Trigger Type
Trigger23 ENS HIZ RMS Capture3Trigger Type
Trigger24 ENS HIZ RMS Capture4 Trigger Type
GE_Digital_Energy_UR_MotStatusKind MotThmPTTR MotStatus ENS Motor status
GE_Digital_Energy_UR_RGooseRxModeKind LGOS RgRxMode ENG Routable GOOSE reception mode
GE_Digital_Energy_UR_RGooseSecEnaKind LGOS SecEna ENG Routable GOOSE security
GE_Digital_Energy_UR_TimeSourceKind TmClkLTMS TmSrc VSS RTC Sync source
