2-60 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 40AD Ethernet Operation Mode 0 to 1 --- 1 F192 1 (Full-
Duplex)
" 40AE DNP Current Scale Factor 0 to 11 --- 1 F660 2 (1)
" 40AF DNP Voltage Scale Factor 0 to 11 --- 1 F660 2 (1)
" 40B0 DNP Power Scale Factor 0 to 11 --- 1 F660 2 (1)
" 40B1 DNP Energy Scale Factor 0 to 11 --- 1 F660 2 (1)
" 40B2 DNP Power Scale Factor 0 to 11 --- 1 F660 2 (1)
" 40B3 DNP Other Scale Factor 0 to 11 --- 1 F660 2 (1)
" 40B4 DNP Current Default Deadband 0 to 100000000 --- 1 F003 30000
" 40B6 DNP Voltage Default Deadband 0 to 100000000 --- 1 F003 30000
" 40B8 DNP Power Default Deadband 0 to 100000000 --- 1 F003 30000
" 40BA DNP Energy Default Deadband 0 to 100000000 --- 1 F003 30000
" 40BC DNP Power Factor Default Deadband 0 to 100000000 -- 1 F003 30000
" 40BE DNP Other Default Deadband 0 to 100000000 --- 1 F003 30000
" 40C0 DNP IIN Time Synchronization Bit Period 1 to 10080 min 1 F001 1440
" 40C1 DNP Message Fragment Size 30 to 2048 --- 1 F001 240
" 40C2 DNP Client Address 3 0 to 4294967295 --- 1 F003 0
" 40C4 DNP Client Address 4 0 to 4294967295 --- 1 F003 0
" 40C6 DNP Client Address 5 0 to 4294967295 --- 1 F003 0
" 40C8 DNP Number of Paired Binary Output
Control Points
0 to 32 --- 1 F001 0
" 40C9 DNP TCP Connection Timeout 10 to 7200 s 1 F001 120
" 40CA DNP Communications Reserved (22 items) 0 to 1 --- 1 F001 0
" 40E0 TCP Port Number for the IEC 60870-5-104
Protocol
0 to 65535 --- 1 F001 2404
" 40E2 IEC 60870-5-104 Protocol Common
Address of ASDU
0 to 65535 --- 1 F001 0
" 40E3 IEC 60870-5-104 Protocol Cyclic Data
Transmission Period
1 to 65535 s 1 F001 60
" 40E4 IEC 60870-5-104 Current Default Threshold 0 to 100000000 --- 1 F003 30000
" 40E6 IEC 60870-5-104 Voltage Default Threshold 0 to 100000000 --- 1 F003 30000
" 40E8 IEC 60870-5-104 Power Default Threshold 0 to 100000000 --- 1 F003 30000
" 40EA IEC 60870-5-104 Energy Default Threshold 0 to 100000000 --- 1 F003 30000
" 40EC IEC 60870-5-104 Power Factor Default
Threshold
0 to1 --- 0.01 F001 100
" 40EE IEC 60870-5-104 Other Default Threshold 0 to 100000000 --- 1 F003 30000
" 40F0 IEC 60870-5-104 Client Address (5 items) 0 to 4294967295 --- 1 F003 0
" 4104 IEC 60870-5-104 Redundancy Port
Enabled/Disabled
0 to 1 --- 1 F126 0 (No)
" 4105 Port 2 IP Address 0 to 4294967295 --- 1 F003 2130706433
" 4107 Port 2 IP Subnet Mask 0 to 4294967295 --- 1 F003 4278190080
" 410B Port 2 Ethernet Operation Mode 0 to 1 --- 1 F192 1 (Full-
Duplex)
" 410C Port 2 Redundancy Enabled 0 to 2 --- 1 F627 0 (None)
" 410D Port 3 IP Address 0 to 4294967295 --- 1 F003 2130706433
" 410F Port 3 IP Subnet Mask 0 to 4294967295 --- 1 F003 4278190080
" 4113 Port 3 Ethernet Operation Mode 0 to 1 --- 1 F192 1 (Full-
Duplex)
" 4117 Default IPv4 Route 0 to 4294967295 --- 1 F003 2130706433
" 4119 Port 2 PRP Mcst Addr --- --- --- F072 0
Products Address Register name Range Units Step Format Default
